產品簡介
DIODES 的 SBR10U200P5 封裝在緊湊的熱效率PowerDI?5封裝中，在高溫下提供低VF和低反向泄漏。它非常適合用于以下應用：

產品規格
品牌        DIODES
型號        SBR10U200P5
名稱        10A超級勢壘整流器
產地        臺灣
封裝        POWERDI?5

產品參數
AEC Qualified Yes
Compliance (Only Automotive supports PPAP) Standard
Configuration Single
Maximum Average Rectified Current IO (A) 10
Peak Repetitive Reverse Voltage VRRM (V) 200
Peak Forward Surge Current IFSM (A) 180
Forward Voltage Drop VF (V) 0.88
@ IF (A) 10
Maximum Reverse Current IR (μA) 100
@ VR (V) 200

主要特征
超低正向電壓降
優異的高溫穩定性
專利超級屏障整流器技術（SBR?）
軟、快速切換能力
+175°C工作接點溫度
無鉛飾面；符合RoHS（注1和2）
不含鹵素和銻。“綠色”裝置（注3）
適用于需要特定變更控制的汽車應用
