數據： 1-Ohm SPDT Analog Switch 5-V/3.3-V Single-Channel 2:1 Multiplexer/Demultiplexer 數據表
The TS5A3153 is a single-pole double-throw (SPDT) analog switch that is designed to operate from 1.65 V to 5.5 V. The device offers a low ON-state resistance and an excellent on-resistance matching with the break-before-make feature, to prevent signal distortion during the transferring of a signal from one channel to another. The device has an excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications.
）NanoStar是德州儀器公司的商標。
| ? |
|---|
| Configuration |
| Number of Channels (#) |
| Power Supply Type |
| Vss (Min) (V) |
| Vss (Max) (V) |
| Vdd (Min) (V) |
| Vdd (Max) (V) |
| Ron (Typ) (Ohms) |
| Bandwidth (MHz) |
| Rating |
| Operating Temperature Range (C) |
| Package Size: mm2:W x L (PKG) |
| Package Group |
| Supply Range (Max) |
| Ron (Max) (Ohms) |
| Input/Output Continuous Current (Max) (mA) |
| Supply Current (Typ) (uA) |
| Supply Current (Max) (uA) |
| Features |
| OFF-state leakage current (Max) (μA) |
| ON-state leakage current (Max) (μA) |
| Input/Output ON-state Capacitance (Typ) (pF) |
| Input/Output OFF-state Capacitance (Typ) (pF) |
| ESD Charged Device Model (kV) |
| ESD HBM (kV) |
| VIL (Max) (V) |
| VIH (Min) (V) |
| ? |
| TS5A3153 |
|---|
| 2:1 SPDT ? ? |
| 1 ? ? |
| Single ? ? |
| N/A ? ? |
| N/A ? ? |
| 1.65 ? ? |
| 5.5 ? ? |
| 0.8 ? ? |
| 100 ? ? |
| Catalog ? ? |
| -40 to 85 ? ? |
| See datasheet (DSBGA) 8VSSOP: 6 mm2: 3.1 x 2(VSSOP) ? ? |
| DSBGA VSSOP ? ? |
| 5.5 ? ? |
| 3.1 ? ? |
| 200 ? ? |
| 0.001 ? ? |
| 0.5 ? ? |
| Powered off protection Break-before-make ? ? |
| 0.15 ? ? |
| 0.15 ? ? |
| 57 ? ? |
| 19 ? ? |
| 1 ? ? |
| 2 ? ? |
| 0.8 ? ? |
| 1.5 ? ? |
