Telit designs wireless data transmission solutions for machine-to-machine applications.

Telit’s product portfolio offers a wide range of innovative and reliable RF solutions ranging from ready-to-use wireless radio modems to OEM RF modules and RF design services.

Solutions from Telit operate in the license-free worldwide ISM frequency bands of 433 MHz， 868 MHz， 915 MHz， and 2.4 GHz and are available in both standardized and proprietary low-power， low-data rate RF technologies for the m2m/industrial markets.

The long-term experience and extensive expertise in cost-effective state-of-the-art radio solutions allow a significant reduction in TCO ［total cost of ownership］ and time-to-market. Additionally， having full IP stack ownership and a multi-chip vendor approach ensure continuity of supply and highly reliable products.

The product line is based on two main family concepts： TinyOne? and ZigBee ?

433 MHz band

■P Frequency： 433.05 – 434.79 MHz

■P Application： Europe， Australia， South Africa

■P Standard： ETSI 300-220

■P Power： 10 mW

■P Duty cycle： 10% to 100%

■P Family： TinyOne? Lite

868 MHz band

915 MHz band

■P Frequency： 902.00 – 928.00 MHz

■P Application： U.S.， Canada， Australia

■P Standard： FCC 15.247

■P Power： 1 W with possibility to have 6dB gain antenna

■P Duty cycle： Frequency Hopping Spread Spectrum， 400 ms allowed per channel， hop on 50 channels min

■P Family：

TinyOne? Plus/Pro

TinyOne? family， consisting of TinyOne? Lite， Tiny-One? Plus， TinyOne? Pro， and TinyOne?2400MC， is a complete line of products with a reduced form factor for easy integration. The family offers pin-to-pin com-patibility and surface mount device （SMD） half moon technology that is dedicated to wireless applications operating in the ISM band （433， 868， 915 and 2.4Ghz）， thus providing efficient power consumption manage-ment， low-data rates， and long distance.

TinyOne? Lite， TinyOne? Plus， TinyOne? Pro and TinyOne? 2400MC are delivered with proprietary standard firmware （S-One stack） and proprietary mesh

firmware （M-One stack）。 Telit’s stack is fully configura-ble and upgradeable over-the-air from a point-to-point communication to a star communication with listen before talk and allows mesh networking with efficient power consumption management. The efficient power management process enables multi-year battery powe-red operation， simple installation， and auto association including self healing and auto-repair functionalities as well as mobility functions.

?
