The MC54/74HC367 is identical in pinout to the LS367. The device inputs are compatible with standard CMOS outputs; with pullup resistors， they are compatible with LSTTL outputs. This device is arranged into 2–bit and 4–bit sections， each having its own active–low Output Enable. When either of the enables is high， the affected buffer outputs are placed into high–impedance states. The HC367 has noninverting outputs. ? Output Drive Capability： 15 LSTTL Loads ? Outputs Directly Interface to CMOS， NMOS， and TTL ? Operating Voltage Range： 2 to 6 V ? Low Input Current： 1 μA ? High Noise Immunity Characteristic of CMOS Devices ? In Compliance with the Requirements Defined by JEDEC Standard No. 7A ? Chip Complexity： 92 FETs or 23 Equivalent Gates
