The MC3359 is designed to detect narrowband FM signals using a 455 kHz ceramic filter for use in FM dual conversion communications equipment. The MC3359 is similar to the MC3357 except that the MC3359。includes oscillator， mixer， limiting amplifier， AFC， quadrature discriminator， op/amp， squelch， scan control， and mute switch. The MC3359 is designed to detect narrowband FM signals using a 455 kHz ceramic filter for use in FM dual conversion communications equipment. The MC3359 is similar to the MC3357 except that the MC3359 has an additional limiting IF stage， an AFC output， and an opposite polarity Broadcast Detector. The MC3359 also requires fewer external parts. For low cost applications requiring VCC below 6.0 V， the MC3361BP，BD are recommended. For applications requiring a fixed， tuned， ceramic quadrature resonator， use the MC3357. For applications requiring dual conversion and RSSI， refer to these devices; MC3335， MC3362 and MC3363. ? Low Drain Current： 3.6 mA （Typical） @ VCC = 6.0 Vdc ? Excellent Sensitivity： Input Limiting Voltage – – 3.0 dB = 2.0 μV （Typical） ? Low Number of External Parts Required ? For Low Voltage and RSSI， use the MC3371。
