Abstract: A resistive feedback network is often used to set the output voltage of a power supply. A mechanical potentiometer (pot)conveniently solves the problem of adjusting a power supply. For easier automatic calibration, a mechanical pot can be replaced witha digital pot. This application note presents a calibration solution that uses a digital pot, because digipots are smaller, do not movewith age or vibration, and can be recalibrated remotely. This proposed solution reduces the susceptibility of the system to thetolerance of the digital pot's end-to-end resistance, making the solution optimal fordesigners. This application note also explainssome of the equations required to calculate the resistor chain values and to use a digital pot in this way. A spreadsheet withstandard reisistor values is available for easy calculations.
