Description The CAV24C02/04/08/16 are 2?Kb， 4?Kb， 8?Kb and 16?Kb respectively CMOS Serial EEPROM devices organized internally as 16/32/64 and 128 pages respectively of 16 bytes each. All devices support both the Standard （100 kHz） as well as Fast （400 kHz） I2C protocol. Data is written by providing a starting address， then loading 1 to 16 contiguous bytes into a Page Write Buffer， and then writing all data to non?volatile memory in one internal write cycle. Data is read by providing a starting address and then shifting out data serially while automatically incrementing the internal address count. External address pins make it possible to address up to eight CAV24C02， four CAV24C04， two CAV24C08 and one CAV24C16 device on the same bus.
