Introduction

　　Engineers designing audio equipment for the high-end audiophile or professional recording markets have　a limited selection of high-resolution signal amplifiers that will meet end-user demands for both　outstanding objective and critical subjective performance. Suitable devices must provide a combination of　state-of-the-art specifications for low noise and ultra-low distortion along with high GBP and preferably　unity gain stability. While nearly all suppliers develop and provide devices optimized for video，　instrumentation， or low power， these applications demand a specification mix that does not necessarily　align with the needs of the high-performance audio engineer. Accordingly， Texas Instruments has　developed a series of high-performance， high-fidelity audio amplifiers specifically optimized for these　applications.

　　The LME49710 / LM4562 are representative of this line of devices and have been optimized for the high　performance and professional community. They provide the designer with unprecedented levels of THD　（0.00003%） and IM （0.00005%） plus very low noise （2.7 nV / √Hz） and GBWP of 55 MHz with output　current of ±26 mA into a 600Ω load. Supply current is extremely low， serving the needs of both portable　products as well as multimedia components utilizing multiple amplifiers.

　　Note that the design philosophy and choices discussed herein will frequently refer to the practices　embraced by the professional and high-performance community as having both objective （measurable） as　well as subjective （audible） merit. The quantification of the contribution of these techniques has been　published in many other documents and will not be included in this document. Included in this approach　are capacitor dielectric choices， power supply impedance considerations， and circuit topology.

　　Objectively， it is understood that best practices are required with device parameter consideration relative　to circuit topology as well as grounding/shielding practices， power supply purity， and other well　documented practices generally applied to sensor conditioning and instrumentation applications.
