了解嵌入式控制器的省電選項，以提高系統的功率效率

　　所有大小的嵌入式控制器提供各種操作模式，以節省電力和/或節省電池的能量，同時系統運行和當它是空閑的。然而，可用模式的數量已經從兩個或三個增加到多達六個?？刂破髟O(shè)計者繼續通過允許系統設計者選擇性地關閉微控制器的不同部分和調整時鐘速率來降低操作功率，以便在執行非時間關鍵任務時減慢控制器的速度。

　　如今，這個行業在許多不同的市場上使用微控制器——消費者、醫療、工業、安全、計算機等。許多這些系統是電池供電，因此功耗是一個關鍵的規格，設計師必須密切關注。即使系統是線運行的，功耗也可以是一個重要的規范，因?yàn)樵S多系統都是密封的外殼，并且在運行過程中產生的熱量必須保持在最低限度，以防止這種系統過熱。能源效率的運作也使得有可能消除風扇或其他方案旨在消除熱量。

　　Tricks of the trade

　　Since the early days of microcontrollers， chip designers most often implemented microcontrollers with static logic rather than dynamic logic so that simple clock gating could be used to stop all processor activity and reduce the power consumed by the controller to near zero （often just the leakage current）。 Static logic allows all the gates or memories to retain their state so that the functions can pick up where they left off when the clock is switched back on. However， dynamic logic requires that the logic elements continually get some activity， much like DRAMs get refreshed， in order to maintain their logic state. Unfortunately that means dynamic logic continually consumes some power even when the processor is idling.
