比較完整的CPLD芯片資料

Features.。。

■ High-performance 3.3-V EEPROM-based programmable logic devices （PLDs） built on second-generation Multiple Array MatriX （MAX?） architecture （see Table 1）

■ 3.3-V in-system programmability （ISP） through the built-in IEEE Std. 1149.1 Joint Test Action Group （JTAG） interface with advanced pin-locking capability – MAX 7000AE device in-system programmability （ISP） circuitry compliant with IEEE Std. 1532 – EPM7128A and EPM7256A device ISP circuitry compatible with IEEE Std. 1532

■ Built-in boundary-scan test （BST） circuitry compliant with IEEE Std. 1149.1

■ Supports JEDEC Jam Standard Test and Programming Language （STAPL） JESD-71

■ Enhanced ISP features – Enhanced ISP algorithm for faster programming （excluding EPM7128A and EPM7256A devices） – ISP_Done bit to ensure complete programming （excluding EPM7128A and EPM7256A devices） – Pull-up resistor on I/O pins during in-system programming

■ Pin-compatible with the popular 5.0-V MAX 7000S devices

■ High-density PLDs ranging from 600 to 10，000 usable gates

■ Extended temperature range

For information on in-system programmable 5.0-V MAX 7000 or 2.5-V MAX 7000B devices， see the MAX 7000 Programmable Logic Device Family Data Sheet or the MAX 7000B Programmable Logic Device Family Data Sheet.
