?? AC04器件包含六個獨立的逆變器。設備執行布爾函數Y = A \。
| Technology Family |
| VCC (Min) (V) |
| VCC (Max) (V) |
| Bits (#) |
| Voltage (Nom) (V) |
| F @ Nom Voltage (Max) (Mhz) |
| ICC @ Nom Voltage (Max) (mA) |
| tpd @ Nom Voltage (Max) (ns) |
| IOL (Max) (mA) |
| IOH (Max) (mA) |
| Schmitt Trigger |
| Rating |
| Operating Temperature Range (C) |
| Pin/Package |
| SN74AC04 | SN54AC04 | SN74AC04-EP | SN74AC04-Q1 |
|---|---|---|---|
| AC | AC | AC | AC |
| 2 | 2 | 2 | 2 |
| 6 | 6 | 6 | 6 |
| 6 | 6 | 6 | 6 |
|
3.3 5 |
3.3 5 |
3.3 5 |
3.3 5 |
| 100 | 100 | 100 | 100 |
| 0.02 | 0.02 | 0.02 | 0.02 |
|
10 7.5 |
11 8.5 |
9 7 |
10 7.5 |
| 24 | 24 | 24 | 24 |
| -24 | -24 | -24 | -24 |
| No | No | No | No |
| Catalog | Military | HiRel Enhanced Product | Automotive |
| -40 to 85 | -55 to 125 | -55 to 125 | -40 to 125 |
|
14PDIP 14SO 14SOIC 14SSOP 14TSSOP |
14CDIP 14CFP 20LCCC |
14SOIC | 14TSSOP |
| 無樣片 |
金額：￥1.04504
