強大的觸摸感應設計技術

　　電容式觸摸傳感器工作在嘈雜的，具有挑戰性的環境。小心注意的硬件和軟件設計技術可顯著提高設計可靠性。

　　本文的目的是描述在嘈雜環境中開發電容觸摸應用程序時的最佳設計實踐。它首先將定義由噪聲引起的問題，并解釋這種噪聲通常如何影響系統。將提供硬件指南，以幫助最大限度地提高應用程序的自然信噪比（SNR）。所述軟件技術將描述用于過濾傳感器信號的一些常用方法，以進一步提高信噪比，并根據電容傳感器的行為作出解碼決定。

　　The hardware design topics covered are：

　　Selecting a sensor size.

　　Determining the sensors‘ separation.

　　Covering material thickness.

　　Using ground planes to your advantage.

　　Designing the sensors’ layout.

　　Selecting an adhesive.

　　Using series resistance on sensors.

　　Choosing VDD to maximize noise immunity.

　　mTouch? sensing solution systems have passed industry test standards in conducted noise， radiated noise， and radiated susceptibility. This article describes the important aspects of capacitive touch design which， when coupled with good PCB techniques， will allow these systems to continue performing in these extreme testing conditions.

　　For information on the basics of capacitive touch sensing and other more advanced topics， visit the Microchip web site.
